Konmed KM-580 4 Channel EMG Biofeedback Device for Rehabilitation

Send Inquiry

Request To Call Back

Konmed KM-580 4 Channel EMG Biofeedback Device for Rehabilitation

Price 25000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Konmed KM-580 4 Channel EMG Biofeedback Device for Rehabilitation Specification

Color
White

Dimension (L*W*H)
22, 15, 6 cm Centimeter (cm)

Function
Neuromuscular Electrical Stimulation (NMES), Transcutaneous Electrical Nerve Stimulation (TENS)

Operating Type
Fully Automatic Digital

Warranty
1 year

Attributes
Rechargeable Lithium Battery

Equipment Type
Clinical Biofeedback Rehabilitation Device

Set Contains
1 KM-580 Biofeedback Stimulator Main Unit

Accuracy
5% Stimulation Output Accuracy mg

Feature
Advanced EMG Biofeedback Technology, Neuromuscular Electrical Stimulation (NMES), Transcutaneous Electrical Nerve Stimulation (TENS)

Operation Mode
Biofeedback / NMES / TENS Therapy

Adhesive Type
Medical Grade Hydrogel

Power
5 W Volt (v)

Material
Medical Grade ABS Plastic Housing

Use
Transcutaneous Electrical Nerve Stimulation (TENS)

Shape
Compact Portable Desktop Design

Portable
Yes

Condition
New

Capacity
2000 mAh Rechargeable Lithium Battery Kg

Power Consumption
5 W Watt (W)

Voltage
DC 5V (USB Rechargeable) Statampere (sA)

Noise Level
Silent Operation db

Size
22, 15, 6 cm

Suitable For Use
Hospitals, Physiotherapy Clinics, Rehabilitation Centers, Neurology Clinics, Urology Clinics, Gynecology Clinics, Sports Medicine Centers & Home Healthcare

Real-Time Operation
Yes Week

Technology
EMG Biofeedback + Neuromuscular Electrical Stimulation (NMES) + TENS

Wall Mounted
No

Storage Instructions
Store in a cool, clean, and dry place.

Magnification Power
Not Applicable mm

Lighting Type
LED Backlit LCD Display

Application
Pelvic Floor Rehabilitation, Muscle Re-Education, Pain Management & Neurological Recovery

Recyclable
No

Recommended For
Cervical, Muscles, Shoulder, Joints, Nerves, Back

Treatment
Drug-Free and Non-Invasive Physiotherapy Treatment

Measuring Range
0-100 mA Adjustable Stimulation Output Rankine

Pressure Range
Not Applicable

Frequency Range
1-150 Hz Adjustable Hertz (HZ)

Usage
Transcutaneous Electrical Nerve Stimulation (TENS), Neuromuscular Electrical Stimulation (NMES)

Age Group
Children, Adults, Women, Infants, Elders

Display
Touch Screen

Power Source
Electric

Weight
500 Grams Grams (g)

Konmed KM-580 4 Channel EMG Biofeedback Device for Rehabilitation Trade Information

Minimum Order Quantity
1 Piece

FOB Port
Delhi

Payment Terms
Paypal, Days after Acceptance (DA), Delivery Point (DP), Letter of Credit (L/C), Cash on Delivery (COD), Cash Advance (CA), Cash in Advance (CID), Cash Against Delivery (CAD), Cheque, Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Western Union

Supply Ability
1 Piece Per Day

Delivery Time
1 Week

Sample Available
Yes

Sample Policy
Free samples are available

Packaging Details
as per communication

Main Export Market(s)
Africa, Eastern Europe, Asia, Central America, South America, Western Europe, Australia, North America, Middle East

Main Domestic Market
All India

Certifications
as per communication customer

About Konmed KM-580 4 Channel EMG Biofeedback Device for Rehabilitation

Biotronix Konmed KM-580 4-Channel EMG Biofeedback Device for Rehabilitation

The Konmed KM-580 4-Channel EMG Biofeedback Device for Rehabilitation is a professional-grade multi-channel rehabilitation system designed to provide comprehensive EMG biofeedback, functional electrical stimulation (FES), neuromuscular electrical stimulation (NMES), electrical triggered stimulation (ETS), and interactive rehabilitation training. Equipped with 4 independent stimulation channels, the KM-580 enables clinicians to simultaneously assess, train, and stimulate multiple muscle groups, making it an ideal solution for advanced neurological, orthopedic, pelvic floor, and sports rehabilitation.

Designed for hospitals, physiotherapy clinics, neurorehabilitation centers, rehabilitation hospitals, sports medicine departments, and research institutions, the KM-580 combines high-precision EMG monitoring with intelligent stimulation technologies to promote neuromuscular re-education, motor relearning, muscle strengthening, and functional recovery.

Key Features

Advanced 4-Channel EMG Biofeedback Technology
Integrated EMG Biofeedback, NMES, FES & ETS Therapy
Four Independent Stimulation Channels
Real-Time Muscle Activity Monitoring
Interactive Visual Biofeedback Training
High-Sensitivity EMG Signal Acquisition
Simultaneous Multi-Muscle Rehabilitation
Intelligent Clinical Assessment Programs
High-Resolution Color Touchscreen Display
Preset and Customizable Treatment Protocols
Comprehensive Patient Database Management
USB Data Export and Progress Reporting
Rechargeable Battery with Portable Design
Medical-Grade Safety Protection System
Designed for Professional Clinical Rehabilitation

Technical Specifications

Specification	Details
Device Model	Konmed KM-580
Therapy Technologies	EMG Biofeedback, NMES, FES, ETS
EMG Channels	4 Independent Channels
Stimulation Channels	4 Independent Output Channels
Output Current	0100 mA Adjustable
Pulse Width	50500 s Adjustable
Stimulation Frequency	1150 Hz Adjustable
Waveform	Symmetrical Biphasic Pulse
EMG Sampling Rate	Up to 1000 Hz
Signal Frequency Response	20500 Hz
Display	High-Resolution Color Touchscreen LCD
Therapy Programs	Preset & User-Customizable
Biofeedback Modes	Visual, Graphical & Interactive
Data Storage	Internal Patient Database with Progress Reports
Connectivity	USB Data Export
Power Supply	Rechargeable Lithium Battery / AC Adapter
Clinical Application	Neurological, Orthopedic & Pelvic Rehabilitation

Applications

Stroke Rehabilitation
Spinal Cord Injury Rehabilitation
Traumatic Brain Injury (TBI)
Parkinson's Disease Rehabilitation
Multiple Sclerosis Rehabilitation
Cerebral Palsy Rehabilitation
Foot Drop Rehabilitation
Hand Function Rehabilitation
Upper Limb Rehabilitation
Lower Limb Rehabilitation
Pelvic Floor Rehabilitation
Neuromuscular Re-Education
Muscle Strengthening
Sports Injury Rehabilitation
Orthopedic Rehabilitation

Benefits

Simultaneously treats and monitors multiple muscle groups
Provides real-time EMG biofeedback for accurate muscle assessment
Combines EMG Biofeedback, NMES, FES, and ETS in one integrated platform
Supports neuromuscular re-education and motor relearning
Helps improve muscle strength, coordination, and functional movement
Enables customized rehabilitation programs based on patient needs
Tracks treatment progress with objective clinical data
Non-invasive and drug-free rehabilitation solution
Increases treatment efficiency with four independent therapy channels
Suitable for neurological, orthopedic, pelvic floor, and sports rehabilitation

Konmed KM-580 4 Channel EMG Biofeedback Device, KM-580 EMG Biofeedback Machine, 4 Channel EMG Biofeedback System, EMG Biofeedback Rehabilitation Equipment, Functional Electrical Stimulation Device, FES Rehabilitation Machine, NMES Therapy Equipment, ETS Electrical Stimulation Machine, Neurological Rehabilitation Device, Physiotherapy Biofeedback Equipment
