Konmed KM-560 Clinical EMG Biofeedback Device with Rehab Mode

Send Inquiry

Request To Call Back

Konmed KM-560 Clinical EMG Biofeedback Device with Rehab Mode

Price 20000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Konmed KM-560 Clinical EMG Biofeedback Device with Rehab Mode Specification

Suitable For Use
physiotherapy

Power Consumption
Power Supply: AC Power / Rechargeable Lithium Battery support Watt (W)

Function
Standard EMG Test (muscle activity assessment) Quick EMG Assessment (fast screening mode) EMG Biofeedback Training & Interactive Gaming

Wall Mounted
orthopedic rehab device

Magnification Power
Not Applicable mm

Storage Instructions
Patient data storage & history tracking

Material
EMG Biofeedback Training & Interactive Gaming

Feature
7-inch TFT LCD Touch Screen with real-time waveform display

Shape
square

Dimension (L*W*H)
15, 20, 25 Inch (in)

Technology
Combination of EMG Biofeedback + Neuromuscular Electrical Stimulation

Voltage
AC 100V-240V, 50/60 Hz Statampere (sA)

Equipment Type
KM-560

Noise Level
EMG stimulation system db

Operating Type
Automatic / Microprocessor Controlled (Digital Touchscreen Operated)

Color
more

Real-Time Operation
Yes Week

Condition
Visual touch screen interface for easy navigation

Warranty
1 year

Capacity
ETS (EMG-Triggered Stimulation-auto-stimulation on threshold) Kg

Size
25

Adhesive Type
rehab clinic equipment

Operation Mode
EMG Biofeedback, ETS, NMES, FES

Use
Clinical-grade design for hospital and rehab center use

Lighting Type
advanced physio device

Attributes
physio treatment machine

Application
Stroke Rehabilitation (CVA Recovery)

Portable
yes

Set Contains
Vaginal / Rectal Probe (for Pelvic Floor Therapy-optional)

Accuracy
High precision EMG signal detection with reliable and stable output mg

Power
Rechargeable battery + AC Adapter Volt (v)

Recyclable
No

Recommended For
Shoulder, Joints, Cervical, Back, Muscles, Nerves

Treatment
Treatment record recall system

Measuring Range
0-1000- V (microvolts) Rankine

Pressure Range
Not Applicable

Frequency Range
1-120 Hz Hertz (HZ)

Usage
Multi-channel output for simultaneous therapy

Age Group
Elders, Children, Adults, Women, Infants

Display
Touch Screen

Power Source
Electric

Weight
10 Kilograms (kg)

Konmed KM-560 Clinical EMG Biofeedback Device with Rehab Mode Trade Information

Minimum Order Quantity
1 Piece

FOB Port
New Delhi

Payment Terms
Cash Against Delivery (CAD), Cash on Delivery (COD), Cash Advance (CA), Cash in Advance (CID), Cheque, Days after Acceptance (DA), Delivery Point (DP), Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Western Union, Letter of Credit (L/C), Paypal

Supply Ability
1 Piece Per Day

Delivery Time
1 Week

Sample Available
Yes

Sample Policy
Free samples available with shipping and taxes paid by the buyer

Packaging Details
as per communication

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
as per communication customer

About Konmed KM-560 Clinical EMG Biofeedback Device with Rehab Mode

Biotronix Konmed KM-560 Clinical EMG Biofeedback Device with Rehab Mode

The Konmed KM-560 Clinical EMG Biofeedback Device with Rehab Mode is a high-performance rehabilitation system designed for accurate muscle assessment, structured therapy delivery, and advanced clinical rehabilitation. This device integrates EMG biofeedback with NMES (Neuromuscular Electrical Stimulation), FES (Functional Electrical Stimulation), and ETS (EMG Triggered Stimulation), enabling real-time monitoring of muscle activity while delivering targeted stimulation for optimal recovery outcomes.

The KM-560 is equipped with a dedicated Rehab Mode, which provides pre-set and customizable rehabilitation programs tailored for various clinical conditions. This allows therapists to deliver consistent, protocol-based treatments while still having the flexibility to adjust parameters according to patient needs. The system converts muscle signals into visual feedback, helping patients improve muscle activation, coordination, and control through active participation.

Key Features

Advanced Clinical EMG Biofeedback with Rehab Mode
4-channel simultaneous output for multi-muscle therapy
NMES, FES, and ETS modes for comprehensive rehabilitation
Dedicated Rehab Mode with pre-set and customizable programs
Real-time EMG waveform monitoring and analysis
7-inch TFT LCD touchscreen interface
Interactive EMG gaming therapy for enhanced patient engagement
Fully adjustable therapy parameters (intensity, frequency, pulse width)
Independent channel control for precise therapy delivery
Patient data storage with session tracking and recall

Applications

Stroke rehabilitation (CVA recovery)
Neuromuscular re-education and coordination training
Pelvic floor rehabilitation (incontinence, postpartum recovery)
Orthopaedic rehabilitation (knee, shoulder, spine, joints)
Sports injury rehabilitation and performance recovery
Muscle strengthening and activation therapy
Pain management and functional recovery

Benefits

Ensures structured therapy with Rehab Mode protocols
Improves muscle awareness and voluntary control
Enhances rehabilitation outcomes and recovery speed
Increases patient engagement through visual and interactive feedback
Provides measurable and trackable therapy progress
Reduces therapist workload with automated rehab programs
Safe, non-invasive, and clinically reliable solution

Technical Specifications

Channels: 4 Channel Output (Independent Multi-Channel Control)
Display: 7-inch TFT LCD Touchscreen with real-time EMG waveform
EMG Measuring Range: 0 1000 V (microvolts)
Frequency Range: 1 120 Hz (adjustable)
Pulse Width: 50 450 s (adjustable)
Output Current: 0 100 mA (adjustable per channel)
Therapy Modes: EMG, NMES, FES, ETS
Rehab Mode: Predefined and customizable rehabilitation protocols
Rehab Programs: 20+ built-in therapy programs
Therapy Control: Adjustable intensity, frequency, pulse width, and timing parameters
Operating System: Microprocessor-controlled digital system
Power Supply: AC 100240V, 50/60 Hz with rechargeable battery support
Output Control: Independent intensity control for each channel
Data Storage: Patient memory with session recording and recall
Training Modes: EMG Test, EMG Game, ETS Training, STIM Programs
Safety Features: Overcurrent protection and a patient safety monitoring system
Treatment Capability: Simultaneous multi-site therapy with clinical precision
Build Type: Clinical tabletop portable design
Weight: Approx. 10 Kg
Usage: Hospitals, physiotherapy clinics, rehabilitation centres

Konmed KM-560 clinical EMG biofeedback device, rehab mode biofeedback machine, 4-channel physiotherapy biofeedback system, NMES FES ETS therapy equipment India, rehabilitation biofeedback device, muscle stimulation rehab machine, stroke rehabilitation biofeedback system, pelvic floor therapy equipment, advanced EMG therapy device India
