Konmed KM-560 Advanced Biofeedback Device with EMG Monitoring

Price 20000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

About Konmed KM-560 Advanced Biofeedback Device with EMG Monitoring

Biotronix Konmed KM-560 Advanced Biofeedback Device with EMG Monitoring

The Konmed KM-560 Advanced Biofeedback Device is a clinically advanced rehabilitation solution engineered for precise EMG monitoring and targeted therapy delivery. This intelligent system provides real-time visualization of muscle activity, allowing therapists to accurately assess performance and guide patients through controlled rehabilitation programs for improved neuromuscular function and faster recovery.

This high-performance device is for physiotherapy clinics, hospitals, and rehabilitation centers, ensuring data-driven treatment with high accuracy and reliability. With its powerful 4-channel EMG capability and integrated therapy modes such as NMES, FES, TENS, and ETS, the KM-560 offers a complete platform for muscle re-education, strengthening, and functional rehabilitation.

Key Features

4-channel EMG Biofeedback System with advanced EMG monitoring
Real-Time EMG Waveform Display for accurate muscle analysis
Multi Therapy Modes: EMG, NMES, FES, TENS, ETS
EMG Triggered Stimulation (ETS) for active rehabilitation
High-Resolution 7-inch TFT LCD Touchscreen
Interactive Biofeedback Training Programs
Pre-set + Custom Therapy Protocols
Patient Data Storage with progress tracking
Microprocessor Controlled for stable and precise operation
Compact, Portable, and Clinical-Grade Design

Applications

Neuromuscular Assessment & Training
Muscle Strengthening & Re-Education
Stroke & Paralysis Rehabilitation
Post-Surgical Recovery
Orthopedic Physiotherapy
Sports Injury Rehabilitation
Pelvic Floor Therapy

Benefits

Provides accurate real-time EMG muscle monitoring
Enhances therapy precision and effectiveness
Improves neuromuscular coordination and control
Accelerates recovery through targeted stimulation
Supports personalized and progressive rehabilitation plans
Ideal for clinics, hospitals, and rehab centers

Technical Specifications

Model: KM-560
Channels: 4 Channel EMG Biofeedback + 4 Channel Stimulation Output
Therapy Modes: EMG Biofeedback, NMES, FES, TENS, ETS (EMG Triggered Stimulation)
Display: 7-inch TFT LCD Touchscreen (High Resolution)
EMG Measuring Range: 0 â€“ 1000 ÂµV
EMG Sensitivity: â‰¤ 1 ÂµV
Stimulation Frequency: 1 â€“ 120 Hz
Pulse Width: 50 â€“ 450 Âµs
Output Intensity: 0 â€“ 100 mA Adjustable
Programs: 20+ preset programs + Custom Modes
EMG Functions: Quick Test, Standard EMG Analysis, Biofeedback Training
Trigger Mode: EMG Triggered (ETS) + Manual Mode
Data Storage: Patient Records & Therapy Progress Tracking
Control System: Microprocessor-Based Operation
Power Supply: AC 100â€“240V, 50/60Hz
Battery: Rechargeable Lithium Battery (Optional Backup)
Safety Features: Auto Shut-Off, Overload Protection, Patient Isolation
Accessories: EMG Sensors, Surface Electrodes, Optional Vaginal/Rectal Probes
Weight: Approx. 8â€“10 Kg
Portability: Portable Clinical Model
Usage: Clinics, Hospitals, Rehabilitation Centers
Warranty: 1 Year
