Konmed KM-560 Advanced Biofeedback Device with Clinical Functions

Price 20000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

About Konmed KM-560 Advanced Biofeedback Device with Clinical Functions

Biotronix Konmed KM-560 Advanced Biofeedback Device with Clinical Functions

The Konmed KM-560 Advanced Biofeedback Device with Clinical Functions is a high-end rehabilitation system designed for accurate muscle assessment, structured therapy delivery, and superior clinical outcomes. This advanced device integrates EMG biofeedback with NMES (Neuromuscular Electrical Stimulation), FES (Functional Electrical Stimulation), and ETS (EMG Triggered Stimulation), enabling real-time monitoring of muscle activity while delivering precise and controlled therapeutic stimulation.

The KM-560 is equipped with clinical functions that support standardized treatment protocols for neurological, orthopedic, and pelvic rehabilitation. These functions allow therapists to perform muscle activation, neuromuscular re-education, strengthening, and functional training with high accuracy. By converting EMG signals into visual feedback, the device helps patients actively engage in therapy and improve muscle coordination, strength, and control.

Key Features

Advanced Biofeedback Device with Clinical Functions
4-channel simultaneous output for multi-muscle therapy
NMES, FES, and ETS modes for comprehensive rehabilitation
Clinical functions for structured and protocol-based treatment
Real-time EMG waveform monitoring and analysis
7-inch TFT LCD touchscreen interface
Interactive EMG gaming therapy for enhanced patient engagement
Adjustable therapy parameters (intensity, frequency, pulse width, timing)
Independent channel control for precise therapy delivery
Patient data storage with session tracking and recall

Applications

Stroke rehabilitation (CVA recovery)
Neuromuscular re-education and coordination training
Pelvic floor rehabilitation (incontinence, postpartum recovery)
Orthopedic rehabilitation (post-surgery, joint recovery)
Sports injury rehabilitation and muscle conditioning
Muscle strengthening and activation therapy
Pain management and functional recovery

Benefits

Supports clinical protocols with advanced therapy functions
Improves muscle awareness and voluntary control
Enhances rehabilitation outcomes and recovery speed
Increases patient engagement through real-time EMG feedback
Provides measurable and trackable therapy progress
Reduces therapist workload with structured therapy modes
Safe, non-invasive, and clinically reliable solution

Technical Specifications

Channels: 4 Channel Output (Independent Multi-Channel Control System)
Display: 7-inch TFT LCD Touchscreen with real-time EMG waveform
EMG Measuring Range: 0 1000 V (microvolts)
Frequency Range: 1 120 Hz (adjustable)
Pulse Width: 50 450 s (adjustable)
Output Current: 0 100 mA (adjustable per channel)
Therapy Modes: EMG, NMES, FES, ETS
Clinical Functions: Muscle activation, neuromuscular re-education, strengthening, and functional training
Therapy Control: Adjustable intensity, frequency, pulse width, ramp time, and timing parameters
Rehab Programs: 20+ built-in clinical protocols
Operation System: Microprocessor-controlled digital system
Power Supply: AC 100240V, 50/60 Hz with rechargeable battery support
Output Control: Independent intensity control for each channel
Data Storage: Patient memory with session recording and recall system
Training Modes: EMG Test, EMG Game, ETS Training, STIM Programs
Safety Features: Overcurrent protection and patient safety monitoring system
Treatment Capability: Simultaneous multi-site therapy with clinical precision
Build Type: Clinical tabletop portable design
Weight: Approx. 10 Kg
Usage: Hospitals, physiotherapy clinics, rehabilitation centers
