Konmed KM-560 4 Channel Physiotherapy Biofeedback mahine
Konmed KM-560 4 Channel Physiotherapy Biofeedback mahine
Konmed KM-560 4 Channel Physiotherapy Biofeedback mahine
Konmed KM-560 4 Channel Physiotherapy Biofeedback mahine
Konmed KM-560 4 Channel Physiotherapy Biofeedback mahine
Konmed KM-560 4 Channel Physiotherapy Biofeedback mahine
Konmed KM-560 4 Channel Physiotherapy Biofeedback mahine
Konmed KM-560 4 Channel Physiotherapy Biofeedback mahine
Konmed KM-560 4 Channel Physiotherapy Biofeedback mahine
Konmed KM-560 4 Channel Physiotherapy Biofeedback mahine
Konmed KM-560 4 Channel Physiotherapy Biofeedback mahine
Konmed KM-560 4 Channel Physiotherapy Biofeedback mahine

Konmed KM-560 4 Channel Physiotherapy Biofeedback mahine

Price 200000.0 INR/ Piece

MOQ : 1 Piece

Konmed KM-560 4 Channel Physiotherapy Biofeedback mahine Specification

  • Real-Time Operation
  • Yes Week
  • Condition
  • Visual touch screen interface for easy navigation
  • Feature
  • 7-inch TFT LCD Touch Screen with real-time waveform display
  • Accuracy
  • High precision EMG signal detection with reliable and stable output mg
  • Equipment Type
  • KM-560
  • Suitable For Use
  • physiotherapy
  • Portable
  • yes
  • Material
  • EMG Biofeedback Training & Interactive Gaming
  • Lighting Type
  • EMG driven rehabilitation equipment
  • Application
  • Stroke Rehabilitation (CVA Recovery)
  • Wall Mounted
  • Konmed KM-560 physiotherapy system
  • Attributes
  • 4 channel therapy stimulator device
  • Set Contains
  • Vaginal / Rectal Probe (for Pelvic Floor Therapy-optional)
  • Power
  • Rechargeable battery + AC Adapter Volt (v)
  • Function
  • Standard EMG Test (muscle activity assessment) Quick EMG Assessment (fast screening mode) EMG Biofeedback Training & Interactive Gaming
  • Adhesive Type
  • muscle recovery physiotherapy solution
  • Operation Mode
  • EMG Biofeedback, ETS, NMES, FES
  • Warranty
  • 1 year
  • Use
  • Clinical-grade design for hospital and rehab center use
  • Magnification Power
  • Not Applicable mm
  • Voltage
  • AC 100V-240V, 50/60 Hz Statampere (sA)
  • Power Consumption
  • Power Supply: AC Power / Rechargeable Lithium Battery support Watt (W)
  • Technology
  • Combination of EMG Biofeedback + Neuromuscular Electrical Stimulation
  • Size
  • 25
  • Dimension (L*W*H)
  • 15, 20, 25 Inch (in)
  • Operating Type
  • Automatic / Microprocessor Controlled (Digital Touchscreen Operated)
  • Capacity
  • ETS (EMG-Triggered Stimulation-auto-stimulation on threshold) Kg
  • Storage Instructions
  • Patient data storage & history tracking
  • Color
  • more
  • Shape
  • square
  • Noise Level
  • EMG biofeedback electrotherapy unit db
  • Recyclable
  • No
  • Recommended For
  • Shoulder, Back, Muscles, Nerves, Joints, Cervical
  • Treatment
  • Treatment record recall system
  • Measuring Range
  • 0-1000- V (microvolts) Rankine
  • Pressure Range
  • Not Applicable
  • Frequency Range
  • 1-120 Hz Hertz (HZ)
  • Usage
  • Multi-channel output for simultaneous therapy
  • Age Group
  • Adults, Women, Elders, Children, Infants
  • Display
  • Touch Screen
  • Power Source
  • Electric
  • Weight
  • 10 Kilograms (kg)


Konmed KM-560 4 Channel Physiotherapy Biofeedback mahine Trade Information

  • Minimum Order Quantity
  • 1 Piece
  • FOB Port
  • New Delhi
  • Payment Terms
  • Paypal, Cash on Delivery (COD), Cash Advance (CA), Cash in Advance (CID), Cheque, Days after Acceptance (DA), Delivery Point (DP), Cash Against Delivery (CAD), Letter of Credit (L/C), Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Western Union
  • Supply Ability
  • 1 Piece Per Day
  • Delivery Time
  • 1 Week
  • Sample Available
  • Yes
  • Sample Policy
  • Free samples available with shipping and taxes paid by the buyer
  • Packaging Details
  • as per communication
  • Main Export Market(s)
  • Australia, Asia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa
  • Main Domestic Market
  • All India
  • Certifications
  • as per communication customer


About Konmed KM-560 4 Channel Physiotherapy Biofeedback mahine

Biotronix Konmed KM-560 4 Channel Physiotherapy Biofeedback Machine

The Konmed KM-560 4 Channel Physiotherapy Biofeedback Equipment is a clinically advanced rehabilitation system designed for accurate muscle assessment, controlled stimulation, and effective physiotherapy treatment. This device integrates EMG biofeedback with NMES (Neuromuscular Electrical Stimulation), FES (Functional Electrical Stimulation), and ETS (EMG Triggered Stimulation), enabling real-time monitoring of muscle activity while delivering targeted therapeutic output.

The KM-560 converts muscle signals into visual feedback, allowing patients to actively participate in therapy and improve muscle activation, coordination, and strength. Its 4-channel output system supports simultaneous treatment of multiple muscle groups, making it highly efficient for physiotherapy clinics, hospitals, and rehabilitation centers.

Key Features

  • Advanced 4 Channel EMG Biofeedback System for Physiotherapy
  • Real-time EMG waveform monitoring and analysis
  • NMES, FES, and ETS modes for comprehensive rehabilitation
  • Simultaneous multi-muscle treatment capability
  • 7-inch TFT LCD touchscreen interface
  • Interactive EMG gaming therapy for patient engagement
  • Adjustable therapy parameters (intensity, frequency, pulse width)
  • Independent channel control for precise therapy delivery
  • Patient data storage with session tracking and recall
  • Microprocessor-controlled digital system

Applications

  • Stroke rehabilitation (CVA recovery)
  • Neuromuscular re-education and coordination training
  • Pelvic floor rehabilitation (incontinence, postpartum recovery)
  • Orthopaedic rehabilitation (knee, shoulder, spine, joints)
  • Sports injury rehabilitation and muscle conditioning
  • Muscle strengthening and activation therapy
  • Pain management and functional recovery

Benefits

  • Improves muscle awareness and voluntary control
  • Enhances rehabilitation outcomes and recovery speed
  • Increases patient engagement through visual feedback
  • Enables measurable and trackable therapy progress
  • Reduces therapist workload with automated therapy modes
  • Safe, non-invasive, and clinically reliable solution

Technical Specifications

  • Channels: 4 Channel Output (Independent Multi-Channel Control System)
  • Display: 7-inch TFT LCD Touchscreen with real-time EMG waveform
  • EMG Measuring Range: 0-1000 V (microvolts)
  • Frequency Range: 1-120 Hz (adjustable)
  • Pulse Width: 50-450 s (adjustable)
  • Output Current: 0-100 mA (adjustable per channel)
  • Therapy Modes: EMG, NMES, FES, ETS
  • Therapy Control: Adjustable intensity, frequency, pulse width, and timing parameters
  • Rehab Programs: 20+ built-in clinical protocols
  • Operating System: Microprocessor-controlled digital system
  • Power Supply: AC 100240V, 50/60 Hz with rechargeable battery support
  • Output Control: Independent intensity control for each channel
  • Data Storage: Patient memory with session recording and recall system
  • Training Modes: EMG Test, EMG Game, ETS Training, STIM Programs
  • Safety Features: Overcurrent protection and patient safety monitoring system
  • Treatment Capability: Simultaneous multi-site therapy with precision control
  • Build Type: Clinical tabletop portable design
  • Weight: Approx. 10 Kg
  • Usage: Hospitals, physiotherapy clinics, rehabilitation centres


Konmed KM-560 physiotherapy biofeedback equipment, 4-channel EMG biofeedback machine India, physiotherapy biofeedback system, NMES FES ETS therapy device, rehabilitation biofeedback equipment India, muscle stimulation physiotherapy machine, stroke rehabilitation biofeedback system, pelvic floor therapy equipment, advanced physiotherapy machine India
