Konmed KM-560 4 Channel Physiotherapy Biofeedback
Konmed KM-560 4 Channel Physiotherapy Biofeedback
Konmed KM-560 4 Channel Physiotherapy Biofeedback
Konmed KM-560 4 Channel Physiotherapy Biofeedback
Konmed KM-560 4 Channel Physiotherapy Biofeedback
Konmed KM-560 4 Channel Physiotherapy Biofeedback
Konmed KM-560 4 Channel Physiotherapy Biofeedback
Konmed KM-560 4 Channel Physiotherapy Biofeedback
Konmed KM-560 4 Channel Physiotherapy Biofeedback
Konmed KM-560 4 Channel Physiotherapy Biofeedback
Konmed KM-560 4 Channel Physiotherapy Biofeedback
Konmed KM-560 4 Channel Physiotherapy Biofeedback
Konmed KM-560 4 Channel Physiotherapy Biofeedback
Konmed KM-560 4 Channel Physiotherapy Biofeedback
Konmed KM-560 4 Channel Physiotherapy Biofeedback
Konmed KM-560 4 Channel Physiotherapy Biofeedback
Konmed KM-560 4 Channel Physiotherapy Biofeedback
Konmed KM-560 4 Channel Physiotherapy Biofeedback
Konmed KM-560 4 Channel Physiotherapy Biofeedback
Konmed KM-560 4 Channel Physiotherapy Biofeedback
Konmed KM-560 4 Channel Physiotherapy Biofeedback
Konmed KM-560 4 Channel Physiotherapy Biofeedback

Konmed KM-560 4 Channel Physiotherapy Biofeedback

Price 20000 INR/ Piece

MOQ : 1 Piece

Konmed KM-560 4 Channel Physiotherapy Biofeedback Specification

  • Warranty
  • 1 year
  • Accuracy
  • High precision EMG signal detection with reliable and stable output mg
  • Size
  • 25
  • Noise Level
  • 4 Channel Physiotherapy EMG Machine db
  • Wall Mounted
  • Konmed KM-560 EMG Biofeedback Device
  • Lighting Type
  • Electrotherapy Biofeedback System
  • Voltage
  • AC 100V-240V, 50/60 Hz Statampere (sA)
  • Adhesive Type
  • ETS Mode Stimulation Device
  • Function
  • Standard EMG Test (muscle activity assessment) Quick EMG Assessment (fast screening mode) EMG Biofeedback Training & Interactive Gaming
  • Attributes
  • EMG Muscle Therapy Equipment
  • Condition
  • Visual touch screen interface for easy navigation
  • Material
  • EMG Biofeedback Training & Interactive Gaming
  • Technology
  • Combination of EMG Biofeedback + Neuromuscular Electrical Stimulation
  • Use
  • Clinical-grade design for hospital and rehab center use
  • Operation Mode
  • EMG Biofeedback, ETS, NMES, FES
  • Operating Type
  • Automatic / Microprocessor Controlled (Digital Touchscreen Operated)
  • Application
  • Stroke Rehabilitation (CVA Recovery)
  • Feature
  • 7-inch TFT LCD Touch Screen with real-time waveform display
  • Power Consumption
  • Power Supply: AC Power / Rechargeable Lithium Battery support Watt (W)
  • Magnification Power
  • Not Applicable mm
  • Power
  • AC Power / Rechargeable support Volt (v)
  • Storage Instructions
  • Patient data storage & history tracking
  • Capacity
  • ETS (EMG-Triggered Stimulation-auto-stimulation on threshold) Kg
  • Equipment Type
  • KM-560
  • Portable
  • yes
  • Suitable For Use
  • physiotherapy
  • Real-Time Operation
  • Yes Week
  • Dimension (L*W*H)
  • 15, 20, 25 Inch (in)
  • Set Contains
  • Vaginal / Rectal Probe (for Pelvic Floor Therapy-optional)
  • Shape
  • square
  • Color
  • more
  • Recyclable
  • No
  • Recommended For
  • Joints, Cervical, Back, Muscles, Nerves, Shoulder
  • Treatment
  • Treatment record recall system
  • Measuring Range
  • 0-1000- V (microvolts) Rankine
  • Pressure Range
  • Not Applicable
  • Frequency Range
  • 1-120 Hz Hertz (HZ)
  • Usage
  • Multi-channel output for simultaneous therapy
  • Age Group
  • Elders, Infants, Children, Adults, Women
  • Display
  • Touch Screen
  • Power Source
  • Electric
  • Weight
  • 10 Kilograms (kg)


Konmed KM-560 4 Channel Physiotherapy Biofeedback Trade Information

  • Minimum Order Quantity
  • 1 Piece
  • FOB Port
  • New Delhi
  • Payment Terms
  • Paypal, Cash Against Delivery (CAD), Cash on Delivery (COD), Cash Advance (CA), Cash in Advance (CID), Cheque, Days after Acceptance (DA), Delivery Point (DP), Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Western Union, Letter of Credit (L/C)
  • Supply Ability
  • 1 Piece Per Day
  • Delivery Time
  • 1 Week
  • Sample Available
  • Yes
  • Sample Policy
  • Free samples available with shipping and taxes paid by the buyer
  • Packaging Details
  • as per communication
  • Main Export Market(s)
  • Western Europe, Middle East, Africa, Australia, Central America, South America, Eastern Europe, Asia, North America
  • Main Domestic Market
  • All India
  • Certifications
  • as per communication customer


About Konmed KM-560 4 Channel Physiotherapy Biofeedback

Biotronix Konmed KM-560 4 Channel Physiotherapy Biofeedback Equipment

The Konmed KM-560 4 Channel Physiotherapy Biofeedback Equipment is a clinically advanced rehabilitation solution designed to deliver precise EMG biofeedback combined with multi-channel electrotherapy for effective physiotherapy treatment. With its powerful 4-channel configuration, this system enables simultaneous monitoring and stimulation of multiple muscle groups, ensuring comprehensive and result-oriented therapy.

This high-performance equipment is for physiotherapy clinics, hospitals, and rehabilitation centers, helping professionals implement accurate, data-driven treatment protocols. With integrated therapy modes such as NMES, FES, TENS, and ETS, the KM-560 provides a complete platform for neuromuscular re-education, muscle strengthening, and functional recovery.

Key Features

  • 4-channel EMG Biofeedback System for multi-muscle physiotherapy
  • Real-Time EMG Monitoring with waveform display
  • Multi Therapy Modes: EMG, NMES, FES, TENS, ETS
  • EMG Triggered Stimulation (ETS) for active rehabilitation
  • 7-inch TFT LCD Touchscreen with intuitive interface
  • Interactive Biofeedback Training Programs
  • Microprocessor-controlled system for stable and precise performance
  • Pre-set + Custom Therapy Programs
  • Patient Data Storage & Progress Tracking
  • Compact, Portable, and Clinical-Grade Design

Applications

  • Neurological Rehabilitation (Stroke, Paralysis)
  • Muscle Re-Education & Strength Training
  • Pelvic Floor Therapy (Urinary Incontinence)
  • Dysphagia (Swallowing Therapy)
  • Post-Surgical Rehabilitation
  • Orthopedic Physiotherapy
  • Sports Injury Recovery

Benefits

  • Enables simultaneous multi-muscle therapy
  • Provides accurate real-time muscle monitoring
  • Enhances neuromuscular coordination and muscle control
  • Accelerates recovery with integrated therapy modes
  • Improves patient engagement through biofeedback training
  • Suitable for clinics, hospitals, and rehabilitation centers

Technical Specifications

  • Model: KM-560
  • Channels: 4 Channel EMG Biofeedback + 4 Channel Stimulation Output
  • Therapy Modes: EMG Biofeedback, NMES, FES, TENS, ETS (EMG Triggered Stimulation)
  • Display: 7-inch TFT LCD Touchscreen (High Resolution)
  • EMG Measuring Range: 0 to 1000 V
  • EMG Sensitivity: < 1 V
  • Stimulation Frequency: 1120 Hz
  • Pulse Width: 50450 s
  • Output Intensity: 0100 mA Adjustable
  • Programs: 20+ Pre-set Programs + Custom Therapy Modes
  • EMG Functions: Quick Test, Standard EMG Analysis, Biofeedback Training
  • Trigger Mode: EMG Triggered (ETS) + Manual Mode
  • Data Storage: Patient Records & Therapy Progress Tracking
  • Control System: Microprocessor-Based Touch Operation
  • Power Supply: AC 100-240V, 50/60Hz
  • Battery: Rechargeable Lithium Battery (Optional Backup)
  • Safety Features: Auto Shut-Off, Overload Protection, Patient Isolation Safety
  • Accessories: EMG Sensors, Surface Electrodes, Optional Vaginal/Rectal Probes
  • Weight: Approx. 810 kg
  • Portability: Portable Clinical Model
  • Usage: Clinics, Hospitals, Rehabilitation Centers
  • Warranty: 1 Year


Konmed KM-560 4-channel physiotherapy biofeedback equipment, EMG physiotherapy machine India, NMES, FES, TENS, ETS electrotherapy unit, rehabilitation equipment for muscle re-education, stroke rehab EMG system, pelvic floor therapy biofeedback device, electrotherapy physiotherapy combo unit, neuromuscular rehabilitation equipment, advanced physiotherapy equipment India
