Konmed KM-560 4 Channel EMG Biofeedback System with Therapy Control

Send Inquiry

Request To Call Back

Konmed KM-560 4 Channel EMG Biofeedback System with Therapy Control

Price 200000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Konmed KM-560 4 Channel EMG Biofeedback System with Therapy Control Specification

Dimension (L*W*H)
15, 20, 25 Inch (in)

Application
Stroke Rehabilitation (CVA Recovery)

Power
Rechargeable battery + AC Adapter Volt (v)

Condition
Visual touch screen interface for easy navigation

Material
EMG Biofeedback Training & Interactive Gaming

Power Consumption
Power Supply: AC Power / Rechargeable Lithium Battery support Watt (W)

Noise Level
EMG biofeedback rehab device db

Shape
square

Real-Time Operation
Yes Week

Operation Mode
EMG Biofeedback, ETS, NMES, FES

Accuracy
High precision EMG signal detection with reliable and stable output mg

Voltage
AC 100V-240V, 50/60 Hz Statampere (sA)

Function
Standard EMG Test (muscle activity assessment) Quick EMG Assessment (fast screening mode) EMG Biofeedback Training & Interactive Gaming

Operating Type
Automatic / Microprocessor Controlled (Digital Touchscreen Operated)

Technology
Combination of EMG Biofeedback + Neuromuscular Electrical Stimulation

Portable
yes

Wall Mounted
Konmed KM-560 physiotherapy machine

Warranty
1 year

Color
more

Use
Clinical-grade design for hospital and rehab center use

Lighting Type
muscle recovery rehab machine

Feature
7-inch TFT LCD Touch Screen with real-time waveform display

Set Contains
Vaginal / Rectal Probe (for Pelvic Floor Therapy-optional)

Attributes
4 channel muscle stimulator

Magnification Power
Not Applicable mm

Adhesive Type
physiotherapy EMG equipment

Storage Instructions
Patient data storage & history tracking

Size
25

Suitable For Use
physiotherapy

Capacity
ETS (EMG-Triggered Stimulation-auto-stimulation on threshold) Kg

Equipment Type
KM-560

Recyclable
No

Recommended For
Shoulder, Joints, Cervical, Back, Muscles, Nerves

Treatment
Treatment record recall system

Measuring Range
0-1000- V (microvolts) Rankine

Pressure Range
Not Applicable

Frequency Range
1-120 Hz Hertz (HZ)

Usage
Multi-channel output for simultaneous therapy

Age Group
Children, Adults, Women, Elders, Infants

Display
Touch Screen

Power Source
Electric

Weight
10 Kilograms (kg)

Konmed KM-560 4 Channel EMG Biofeedback System with Therapy Control Trade Information

Minimum Order Quantity
1 Piece

FOB Port
New Delhi

Payment Terms
Paypal, Cash Against Delivery (CAD), Cash on Delivery (COD), Cash Advance (CA), Cash in Advance (CID), Cheque, Days after Acceptance (DA), Delivery Point (DP), Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Western Union, Letter of Credit (L/C)

Supply Ability
1 Piece Per Day

Delivery Time
1 Week

Sample Available
Yes

Sample Policy
Within a certain price range free samples are available

Packaging Details
as per communication

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
as per communication customer

Konmed KM-560 4 Channel EMG Biofeedback System with Therapy Control About

Biotronix Konmed KM-560 4 Channel EMG Biofeedback System with Therapy Control

The Konmed KM-560 4 Channel EMG Biofeedback System with Therapy Control is a clinically advanced rehabilitation solution designed for precise muscle assessment, controlled stimulation, and structured physiotherapy treatment. This system integrates EMG biofeedback with NMES (Neuromuscular Electrical Stimulation), FES (Functional Electrical Stimulation), and ETS (EMG Triggered Stimulation), enabling real-time monitoring of muscle activity while delivering targeted and adjustable therapy.

The KM-560 stands out with its therapy control functionality, allowing clinicians to fine-tune parameters such as intensity, frequency, pulse width, and timing for personalized treatment protocols. By converting muscle signals into visual feedback, the device helps patients improve muscle activation, coordination, and strength through active participation.

Key Features

Advanced 4 Channel EMG Biofeedback System with Therapy Control
Real-time EMG monitoring with waveform visualization
NMES, FES, and ETS modes for comprehensive rehabilitation
Fully adjustable therapy control (intensity, frequency, pulse width, timing)
Simultaneous multi-muscle treatment capability
7-inch TFT LCD touchscreen interface
Interactive EMG gaming therapy for enhanced patient engagement
Independent channel control for precise therapy delivery
Patient data storage with session tracking and recall
Microprocessor-controlled digital system

Applications

Stroke rehabilitation (CVA recovery)
Neuromuscular re-education and muscle coordination
Pelvic floor rehabilitation (incontinence, postpartum recovery)
Orthopedic rehabilitation (knee, shoulder, spine, joints)
Sports injury rehabilitation and muscle conditioning
Muscle strengthening and activation therapy
Pain management and functional recovery

Benefits

Enables precise and customizable therapy control
Improves muscle awareness and voluntary control
Enhances rehabilitation outcomes and recovery speed
Increases patient engagement through visual feedback
Provides measurable and trackable therapy progress
Reduces therapist workload with automated and programmable modes
Safe, non-invasive, and clinically effective solution

Technical Specifications

Channels: 4 Channel Output (Independent Multi-Channel Control System)
Display: 7-inch TFT LCD Touchscreen with real-time EMG waveform
EMG Measuring Range: 0 1000 V (microvolts)
Frequency Range: 1 120 Hz (adjustable)
Pulse Width: 50 450 s (adjustable)
Output Current: 0 100 mA (adjustable per channel)
Therapy Modes: EMG, NMES, FES, ETS
Therapy Control System: Adjustable intensity, frequency, pulse width, ramp time, and timing parameters
Rehab Programs: 20+ pre-set clinical protocols
Operation System: Microprocessor-controlled digital system
Power Supply: AC 100240V, 50/60 Hz with rechargeable battery support
Output Control: Independent intensity control for each channel
Data Storage: Patient memory with session recording and recall
Training Modes: EMG Test, EMG Game, ETS Training, STIM Programs
Safety Features: Overcurrent protection and patient safety monitoring system
Treatment Capability: Simultaneous multi-site therapy with precision control
Build Type: Clinical tabletop portable design
Weight: Approx. 10 Kg
Usage: Hospitals, physiotherapy clinics, rehabilitation centers
