Konmed KM-560 4 Channel EMG Biofeedback System with Monitoring

Send Inquiry

Request To Call Back

Konmed KM-560 4 Channel EMG Biofeedback System with Monitoring

Price 200000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Konmed KM-560 4 Channel EMG Biofeedback System with Monitoring Specification

Adhesive Type
physiotherapy treatment for functional recovery

Operating Type
Automatic / Microprocessor Controlled (Digital Touchscreen Operated)

Magnification Power
Not Applicable mm

Set Contains
Vaginal / Rectal Probe (for Pelvic Floor Therapy-optional)

Portable
yes

Function
Standard EMG Test (muscle activity assessment) Quick EMG Assessment (fast screening mode) EMG Biofeedback Training & Interactive Gaming

Feature
7-inch TFT LCD Touch Screen with real-time waveform display

Operation Mode
EMG Biofeedback, ETS, NMES, FES

Wall Mounted
rehabilitation equipment for functional movement

Size
25

Use
Clinical-grade design for hospital and rehab center use

Color
more

Application
Stroke Rehabilitation (CVA Recovery)

Power Consumption
Power Supply: AC Power / Rechargeable Lithium Battery support Watt (W)

Warranty
1 year

Noise Level
smart functional training physiotherapy device db

Storage Instructions
Patient data storage & history tracking

Condition
Visual touch screen interface for easy navigation

Material
EMG Biofeedback Training & Interactive Gaming

Real-Time Operation
Yes Week

Dimension (L*W*H)
15, 20, 25 Inch (in)

Suitable For Use
physiotherapy

Power
Rechargeable battery + AC Adapter Volt (v)

Attributes
neural functional rehabilitation machine

Technology
Combination of EMG Biofeedback + Neuromuscular Electrical Stimulation

Accuracy
High precision EMG signal detection with reliable and stable output mg

Voltage
AC 100V-240V, 50/60 Hz Statampere (sA)

Lighting Type
high performance EMG functional machine

Equipment Type
KM-560

Shape
square

Capacity
ETS (EMG-Triggered Stimulation-auto-stimulation on threshold) Kg

Recyclable
No

Recommended For
Joints, Muscles, Back, Nerves, Shoulder, Cervical

Treatment
Treatment record recall system

Measuring Range
0-1000- V (microvolts) Rankine

Pressure Range
Not Applicable

Frequency Range
1-120 Hz Hertz (HZ)

Usage
Multi-channel output for simultaneous therapy

Age Group
Children, Adults, Women, Elders, Infants

Display
Touch Screen

Power Source
Electric

Weight
10 Kilograms (kg)

Konmed KM-560 4 Channel EMG Biofeedback System with Monitoring Trade Information

Minimum Order Quantity
1 Piece

FOB Port
New Delhi

Payment Terms
Paypal, Cash Against Delivery (CAD), Cash on Delivery (COD), Cash Advance (CA), Cash in Advance (CID), Cheque, Days after Acceptance (DA), Delivery Point (DP), Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Western Union, Letter of Credit (L/C)

Supply Ability
1 Piece Per Day

Delivery Time
1 Week

Sample Available
Yes

Sample Policy
Free samples available with shipping and taxes paid by the buyer

Packaging Details
as per communication

Main Export Market(s)
Asia, Australia, Central America, North America, Western Europe, Middle East, Africa, South America, Eastern Europe

Main Domestic Market
All India

Certifications
as per communication customer

Konmed KM-560 4 Channel EMG Biofeedback System with Monitoring About

Biotronix Konmed KM-560 4 Channel EMG Biofeedback System with Monitoring

The Konmed KM-560 4 Channel EMG Biofeedback System with Monitoring is a clinically advanced rehabilitation solution designed for precise muscle assessment, real-time monitoring, and effective physiotherapy treatment. This system integrates EMG biofeedback with NMES (Neuromuscular Electrical Stimulation), FES (Functional Electrical Stimulation), and ETS (EMG Triggered Stimulation), enabling continuous tracking of muscle activity while delivering targeted therapeutic stimulation.

The KM-560 features an advanced monitoring system, allowing therapists to observe muscle performance, response to stimulation, and therapy progress in real time. By converting EMG signals into visual waveforms, it helps patients actively engage in therapy while improving muscle activation, coordination, and strength.

The 7-inch touchscreen interface, interactive EMG training modules, and patient data management system.

Key Features

Advanced 4-Channel EMG Biofeedback System with Monitoring
Real-time EMG waveform display and therapy tracking
NMES, FES, and ETS modes for comprehensive rehabilitation
Continuous monitoring of muscle activity and response
4-channel simultaneous output for multi-muscle therapy
7-inch TFT LCD touchscreen interface
Interactive EMG gaming therapy for enhanced patient engagement
Adjustable therapy parameters (intensity, frequency, pulse width)
Independent channel control for precise therapy delivery
Patient data storage with session tracking and recall

Applications

Stroke rehabilitation (CVA recovery)
Neuromuscular re-education and coordination training
Pelvic floor rehabilitation (incontinence, postpartum recovery)
Orthopedic rehabilitation (knee, shoulder, spine, joints)
Sports injury rehabilitation and muscle conditioning
Muscle strengthening and activation therapy
Pain management and functional recovery

Benefits

Enables accurate real-time monitoring of therapy sessions
Improves muscle awareness and voluntary control
Enhances rehabilitation outcomes with measurable data
Increases patient engagement through visual feedback
Provides trackable and consistent therapy progress
Reduces therapist workload with monitoring support
Safe, non-invasive, and clinically reliable solution

Technical Specifications

Channels: 4 Channel Output (Independent Multi-Channel Control System)
Display: 7-inch TFT LCD Touchscreen with real-time EMG waveform
EMG Measuring Range: 0 1000 V (microvolts)
Frequency Range: 1 120 Hz (adjustable)
Pulse Width: 50 450 s (adjustable)
Output Current: 0 100 mA (adjustable per channel)
Therapy Modes: EMG, NMES, FES, ETS
Monitoring System: Real-time muscle activity tracking and analysis
Therapy Control: Adjustable intensity, frequency, pulse width, and timing parameters
Rehab Programs: 20+ built-in clinical protocols
Operation System: Microprocessor-controlled digital system
Power Supply: AC 100240V, 50/60 Hz with rechargeable battery support
Output Control: Independent intensity control for each channel
Data Storage: Patient memory with session recording and recall system
Training Modes: EMG Test, EMG Game, ETS Training, STIM Programs
Safety Features: Overcurrent protection and patient safety monitoring system
Treatment Capability: Simultaneous multi-site therapy with monitoring support
Build Type: Clinical tabletop portable design
Weight: Approx. 10 Kg
Usage: Hospitals, physiotherapy clinics, rehabilitation centers
