Konmed KM-560 4 Channel EMG Biofeedback Device with Advanced Therapy

Send Inquiry

Request To Call Back

Konmed KM-560 4 Channel EMG Biofeedback Device with Advanced Therapy

Price 200000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Konmed KM-560 4 Channel EMG Biofeedback Device with Advanced Therapy Specification

Adhesive Type
ETS Mode Stimulation Device

Function
Standard EMG Test (muscle activity assessment) Quick EMG Assessment (fast screening mode) EMG Biofeedback Training & Interactive Gaming

Warranty
1 year

Material
EMG Biofeedback Training & Interactive Gaming

Application
Stroke Rehabilitation (CVA Recovery)

Magnification Power
Not Applicable mm

Use
Clinical-grade design for hospital and rehab center use

Technology
Combination of EMG Biofeedback + Neuromuscular Electrical Stimulation

Noise Level
4 Channel Physiotherapy EMG Machine db

Accuracy
High precision EMG signal detection with reliable and stable output mg

Storage Instructions
Patient data storage & history tracking

Voltage
AC 100V-240V, 50/60 Hz Statampere (sA)

Portable
yes

Lighting Type
Electrotherapy Biofeedback System

Wall Mounted
Konmed KM-560 EMG Biofeedback Device

Condition
Visual touch screen interface for easy navigation

Real-Time Operation
Yes Week

Operating Type
Automatic / Microprocessor Controlled (Digital Touchscreen Operated)

Capacity
ETS (EMG-Triggered Stimulation-auto-stimulation on threshold) Kg

Equipment Type
KM-560

Power
Rechargeable battery + AC Adapter Volt (v)

Shape
square

Power Consumption
Power Supply: AC Power / Rechargeable Lithium Battery support Watt (W)

Operation Mode
EMG Biofeedback, ETS, NMES, FES

Suitable For Use
physiotherapy

Size
25

Attributes
Advanced Therapy EMG Equipment

Dimension (L*W*H)
15, 20, 25 Inch (in)

Feature
7-inch TFT LCD Touch Screen with real-time waveform display

Color
more

Set Contains
Vaginal / Rectal Probe (for Pelvic Floor Therapy-optional)

Recyclable
No

Recommended For
Shoulder, Joints, Cervical, Back, Muscles, Nerves

Treatment
Treatment record recall system

Measuring Range
0.1 Hz-120 Hz Rankine

Pressure Range
Not Applicable

Frequency Range
1-120 Hz Hertz (HZ)

Usage
Multi-channel output for simultaneous therapy

Age Group
Women, Elders, Infants, Children, Adults

Display
Touch Screen

Power Source
Electric

Weight
10 Kilograms (kg)

Konmed KM-560 4 Channel EMG Biofeedback Device with Advanced Therapy Trade Information

Minimum Order Quantity
1 Piece

FOB Port
New Delhi

Payment Terms
Paypal, Cash Against Delivery (CAD), Cash on Delivery (COD), Cash Advance (CA), Cash in Advance (CID), Cheque, Days after Acceptance (DA), Delivery Point (DP), Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Western Union, Letter of Credit (L/C)

Supply Ability
1 Piece Per Day

Delivery Time
1 Week

Sample Available
Yes

Sample Policy
Free samples available with shipping and taxes paid by the buyer

Packaging Details
as per communication

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
as per communication customer

Konmed KM-560 4 Channel EMG Biofeedback Device with Advanced Therapy About

Biotronix Konmed KM-560 4 Channel EMG Biofeedback Device with Advanced Therapy

The Konmed KM-560 4 Channel EMG Biofeedback Device is a clinically advanced rehabilitation solution engineered to deliver high-precision EMG biofeedback combined with advanced therapy capabilities. Designed for modern physiotherapy environments, this intelligent system enables real-time monitoring of muscle activity while providing targeted electrical stimulation for effective neuromuscular re-education, strengthening, and functional recovery.

This high-performance device is for physiotherapy clinics, hospitals, and rehabilitation centers, ensuring accurate, consistent, and result-driven therapy. With its powerful 4-channel EMG capability and integrated therapy modes such as NMES, FES, TENS, and ETS, the KM-560 offers a complete platform for advanced rehabilitation and multi-muscle treatment.

Key Features

4-channel EMG Biofeedback System with advanced therapy modes
Simultaneous Multi-Muscle Monitoring & Stimulation
Real-Time EMG Monitoring with waveform display
Multi Therapy Modes: EMG, NMES, FES, TENS, ETS
EMG Triggered Stimulation (ETS) for active therapy
7-inch TFT LCD Touchscreen with intuitive interface
Advanced Pre-set + Custom Therapy Programs
Interactive Biofeedback Training Modules
Patient Data Storage & Progress Tracking
Microprocessor Controlled for stable and precise performance
Compact, Portable, and Clinical-Grade Design

Applications

Advanced Physiotherapy & Rehabilitation
Neurological Rehabilitation (Stroke, Paralysis)
Muscle Re-Education & Strength Training
Post-Surgical Recovery
Orthopedic Physiotherapy
Sports Injury Rehabilitation
Pelvic Floor Therapy

Benefits

Enables advanced multi-muscle therapy in one system
Provides accurate real-time EMG-based monitoring
Enhances treatment precision and therapy effectiveness
Improves neuromuscular coordination and muscle control
Accelerates recovery with targeted therapy modes
Supports customized and progressive rehabilitation plans

Technical Specifications

Model: KM-560
Channels: 4 Channel EMG Biofeedback + 4 Channel Stimulation Output
Therapy Modes: EMG Biofeedback, NMES, FES, TENS, ETS (EMG Triggered Stimulation)
Display: 7-inch TFT LCD Touchscreen (High Resolution)
EMG Measuring Range: 0 to 1000 V
EMG Sensitivity: < 1 V
Stimulation Frequency: 1120 Hz
Pulse Width: 50450 s
Output Intensity: 0100 mA Adjustable
Programs: 20+ preset programs + Custom Advanced Therapy Modes
EMG Functions: Quick Test, Standard EMG Analysis, Biofeedback Training
Trigger Mode: EMG Triggered (ETS) + Manual Mode
Data Storage: Patient Records & Therapy Progress Tracking
Control System: Microprocessor-Based Operation
Power Supply: AC 100-240V, 50/60Hz
Battery: Rechargeable Lithium Battery (Optional Backup)
Safety Features: Auto Shut-Off, Overload Protection, Patient Isolation
Accessories: EMG Sensors, Surface Electrodes, Optional Vaginal/Rectal Probes
Weight: Approx. 810 kg
Portability: Portable Clinical Model
Usage: Clinics, Hospitals, Rehabilitation Centers
Warranty: 1 Year
