Konmed KM-560 4 Channel EMG Biofeedback Device for Clinic

Price 20000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

About Konmed KM-560 4 Channel EMG Biofeedback Device for Clinic

Biotronix Konmed KM-560 4 Channel EMG Biofeedback Device for Clinics

The Konmed KM-560 4 Channel EMG Biofeedback Device is a clinically advanced rehabilitation solution designed for modern physiotherapy clinics requiring precision, efficiency, and multi-functional therapy capabilities. This intelligent system combines real-time EMG biofeedback with multi-channel electrotherapy, allowing therapists to monitor muscle activity accurately while delivering targeted stimulation for effective treatment outcomes.

This high-performance device is tailored for clinical environments, ensuring consistent, data-driven rehabilitation. With its powerful 4-channel EMG capability and integrated therapy modes such as NMES, FES, TENS, and ETS, the KM-560 provides a complete platform for muscle strengthening, neuromuscular re-education, and functional recovery.

Key Features

4-channel EMG Biofeedback System for clinic use
Simultaneous Multi-Muscle Monitoring & Stimulation
Real-Time EMG Monitoring with waveform display
Multi Therapy Modes: EMG, NMES, FES, TENS, ETS
EMG Triggered Stimulation (ETS) for active therapy
7-inch TFT LCD Touchscreen with intuitive interface
Interactive Biofeedback Training Programs
Pre-set + Custom Therapy Protocols
Patient Data Storage with progress tracking
Microprocessor Controlled for stable performance
Compact, Portable, and Clinical-Grade Design

Applications

Physiotherapy Clinics & Rehab Centers
Neurological Rehabilitation (Stroke, Paralysis)
Muscle Re-Education & Strength Training
Post-Surgical Recovery
Orthopedic Physiotherapy
Pelvic Floor Therapy
Sports Injury Rehabilitation

Benefits

Ideal for high-performance clinical environments
Enables multi-muscle therapy in a single session
Provides accurate real-time muscle feedback
Enhances neuromuscular coordination and control
Improves treatment efficiency and patient outcomes
Supports customized and progressive therapy plans

Technical Specifications

Model: KM-560
Channels: 4 Channel EMG Biofeedback + 4 Channel Stimulation Output
Therapy Modes: EMG Biofeedback, NMES, FES, TENS, ETS (EMG Triggered Stimulation)
Display: 7-inch TFT LCD Touchscreen (High Resolution)
EMG Measuring Range: 0 â€“ 1000 ÂµV
EMG Sensitivity: â‰¤ 1 ÂµV
Stimulation Frequency: 1 â€“ 120 Hz
Pulse Width: 50 â€“ 450 Âµs
Output Intensity: 0 â€“ 100 mA Adjustable
Programs: 20+ preset programs + Custom Modes
EMG Functions: Quick Test, Standard EMG Analysis, Biofeedback Training
Trigger Mode: EMG Triggered (ETS) + Manual Mode
Data Storage: Patient Records & Therapy Progress Tracking
Control System: Microprocessor-Based Operation
Power Supply: AC 100â€“240V, 50/60Hz
Battery: Rechargeable Lithium Battery (Optional Backup)
Safety Features: Auto Shut-Off, Overload Protection, Patient Isolation
Accessories: EMG Sensors, Surface Electrodes, Optional Vaginal/Rectal Probes
Weight: Approx. 8â€“10 Kg
Portability: Portable Clinical Model
Usage: Clinics, Hospitals, Rehabilitation Centers
Warranty: 1 Year
